- Micro-controller-based technology with high contrast, easy to read OLED display
- Range: 0 – 20 ppm
- Resolution: 0.01 ppm
- Data logging capability with Gas conc., TWA conc., Date & Time information
- Audible / Visual alarm
- USB interface with PC
- Gas: Phosphine
- Range: 0-20 ppm
- Resolution: 0.1 ppm
- Sensors: Electrochemical Sensor
- Accuracy: Inherently +/- 2% (but also depends on the calibration gas accuracy and calibration method)
- Drift: Less than 2% of the signal per month at constant temperature and pressure.
- Gas sampling: Diffusion
- Alarms: User-Settable Lo Alarm comes with Visual Blue LED indication.
-
- User-Settable Hi Alarm comes with 85Db Audio alarm and
- Visual Red LED indication with optional vibrational alarm.
- TWA and STEL alarms can be provided.
- Data logging: As standard, with gas concentration, date & time
- Power source: 7.4 V Li-ion rechargeable battery pack
- Runtime: 7 – 8 hours when battery full charged.
- Data Transfer/Print: USB (wired) communication from instrument to computer.
- Function keys: 4-keys for basic operation/setting & calibration.
- Operating temperature: -10° to 50° C
- Display: 8×2 Alphanumeric OLED display
- Instrument Enclosure: ABS Plastic
- Ingress Protection: IP 65
- Size: Height = 130 mm
- Width = 70 mm
- Depth = 35 mm
- Weight: Approx. 300 grams
- Certification: CIMFR & CCOE (PESO) approval: Ex ib IIA IIB T4
- CE
