Features
- Advanced micro-processor based technology
- Soft power ON/OFF
- Accurate, Handy and easy to use
- Easy to replace removable battery compartment
- Powerful inbuilt air sampling pump (30 m sample draw capability) for remote sampling.
- On-board memory, stores test results along with date and time stamp
- USB based communication with Computer
Applications
- Refineries
- Pharma industries
- Chemical industries
- Industrial Safety
Specification
- Sensors: Electrochemical/NDIR/PID/Solid state sensor
- Accuracy: Inherently +/- 2% FS (but also depends on the calibration gas & method)
- Drift: less than 2% of the signal per month at constant temperature and pressure.
- Sampling modes: Draws Gas sample on continuous basis. Pump remains ON till SET key is pressed to stop sampling.
- Alarm set point: One user settable alarm set point (for low range detectors)
- Data Storage: Provision to store test records with gas conc. and alarm set points along with date and time
- Power source: 7.4V mAh Li-ion rechargeable battery pack
- Inbuilt Pump Flow Rate: 400 to 800 ml/min
- Power: 3.5V DC, 60 mA
- Runtime: About 6 – 8 hours
- Data Transfer: USB communication for data transfer from instrument to computer
- Function keys: UP, DOWN, SET & ENTER
- Operating temperature: -10 °C to 50 °C
- Display: Large 20 x 4 Alphanumeric OLED
- Instrument Enclosure: High Impact ABS
- Size: Height = 190 mm Depth = 40 mm Width1 = 110 mm Width2 = 65 mm
- Weight: 500 g
- Accessories: Dust filter, battery charger, data downloading cable and outlet coupler.
Gas List
| Gas Name |
Model No | Ordering Code | Range | Resolution | Sensor Type | Data Sheet |
| Ammonia |
282PM |
EF001101 |
0-100 PPM | 1 PPM |
EC |
 |
| Ammonia |
282PM |
EF001324 |
0-1000 PPM | 1 PPM |
EC |
|
| Carbon Dioxide |
225PM |
EF000970 |
0-5 %V/V | 0.01% V/V |
NDIR |
|
| Carbon Dioxide |
225PM |
EF000807 |
0-100% V/V | 1% V/V |
NDIR |
|
| Hydrogen |
290PM |
EF001100 |
0-1000 PPM | 1 PPM |
EC |
|
| Hydrogen Chloride |
270PM |
EF001175 |
0-20 PPM | 0.1 PPM |
EC |
|
| Hydrogen Cyanide |
275PM |
EF000962 |
0-100 PPM | 1 PPM |
EC |
|
| Hydrogen Fluoride |
272PM |
EF000937 |
0-10 PPM | 0.1 PPM |
EC |
|
| Hydrogen Sulphide |
230PM |
EF001337 |
0-100 PPM | 1 PPM |
EC |
|
| Mercaptan |
235PM |
EF001278 |
0-20 PPM | 0.1 PPM |
EC |
|
| Methane |
299PM |
EF000938 |
0-100 % LEL | 1 % LEL |
Pellistor |
|
| Nitrogen Dioxide |
281PM |
EF001102 |
0-20 PPM | 0.1 PPM |
EC |
|
| Sulphur Dioxide |
240PM |
EF000936 |
0-2000 PPM | 1 PPM |
EC |
|
| Sulphur Dioxide |
240PM |
EF001103 |
0-20 PPM | 0.1 PPM |
EC |
|
| VOC (Isobutylene) |
299PM |
EF000954 |
0-4000 PPM | 1 PPM |
PID |
|
| VOC (Isobutylene) |
299PM |
EF000811 |
0-1000 PPM | 1 PPM |
PID |
|
| VOC (Isobutylene) |
299PM |
EF001107 |
0-40 PPM | 1 PPM |
PID |
|
