Features
Enhanced Resolution, Faster Inspections
-
Improved Contrast for Faster Troubleshooting
Use FLIR 1-Touch Level/Span to instantly improve image contrast and highlight potential electrical or mechanical issues.
-
Features to Help with Diagnosis
The E54 measures up to 650°C (1202°F), offers 3 spotmeters, and displays the max/min temperature within an area live, on-screen.
-
Streamlined Reporting
Onboard integration with FLIR routing software*, automatic image upload directly to the FLIR Ignite cloud library, a built-in mic for voice annotation, and report generation features all help the E54 streamline your workday. (*Optional accessory software)
FLIR Ignite™ for Exx-Series
Improve your team’s efficiency and capabilities with the FLIR Ignite cloud solution. Directly upload, organize, and share images from your Wi-Fi connected FLIR Exx-Series camera. Keep your data safe in one place and easily accessible from any device.
Downloads
Specifications
- IR Resolution
- 320 × 240 pixels
- Thermal Sensitivity/NETD
- <40 mK at 30°C (86°F)
- Accuracy
- ±2°C (±3.6°F) or ±2% of the reading
- Digital Camera
- 5 MP, with built-in LED photo/video lamp
- Display
- 4″, 640 × 480 pixel touchscreen LCD with auto-rotation
- Storage Media
- Removable SD card
Imaging & Optical
- Color Palettes
- Iron, Rainbow, Rainbow HC, White hot, Black hot, Arctic, Lava
- Detector Type and Pitch
- Uncooled microbolometer, 17 µm
- Digital Camera
- 5 MP, with built-in LED photo/video lamp
- Digital Zoom
- 1-4× continuous
- f-number
- 1.3
- Focus
- Manual
- Image Frequency
- 30 Hz
- IR Resolution
- 320 × 240 pixels
- Lens Identification
- NA
- Minimum Focus Distance
- 0.15 m
- Non-radiometric IR video streaming
- H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi
- Picture-in-Picture
- Centered infrared area on the visual image
- Radiometric IR video recording
- Real-time radiometric recording (.csq)
- Radiometric IR video streaming
- Yes, over UVC
- Spectral Range
- 7.5-14 µm
- Thermal Sensitivity/NETD
- <40 mK at 30°C (86°F)
- UltraMax
- No
- Viewfinder
- No
Measurement & Analysis
- Accuracy
- ±2°C (±3.6°F) or ±2% of the reading
- Measurement Presets
- No measurements, Center spot, Hot spot, Cold spot, 3 spots, Hot spot–Spot
- Object Temperature Range
- -20 to 120°C (-4 to 248°F); 0 to 650°C (32 to 1202°F)
- Spot Meter
- 3 ea. in live mode
User Interface
- Display
- 4″, 640 × 480 pixel touchscreen LCD with auto-rotation
- Text
- Predefined list or touchscreen keyboard
- Voice
- 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth®
Power
- Battery operating time
- > 2.5 hours at 25°C (68°F) and typical use
- Battery Type
- Rechargeable Li-ion battery
Environmental & Certifications
- Operating Temperature Range
- -15 to 50°C (5 to 122°F)
- Safety
- EN/UL/CSA/PSE 60950-1
- Storage Temperature Range
- -40 to 70°C (-40 to 158°F)
General
- FLIR Inspection Route
- Enabled in camera
- Laser Pointer
- Yes
- Packaging
- Infrared camera with lens, 2 batteries, battery charger, hard transport case, lanyards, front lens cap, power supplies, printed documentation, SD card (8 GB), cables (USB 2.0 A to USB Type-C, USB Type-C to HDMI, USB Type-C to USB Type-C).
