Features
Reduce diagnostic time, simplify reporting
-
Identify and troubleshoot
Quickly find hidden faults and reduce diagnostic time with MSX and 128 × 96 true thermal imaging
-
Document and share
Directly upload images using FLIR Ignite cloud connectivity, then create professional reports and email them to customers
-
Rugged, reliable, compact
Take the pocket-portable C3-X with you to every job – it’s IP54 rated for protection against water and dust and designed to withstand a 2 m drop
Professional Reports that Help Your Customer and Your Business
The right image analysis and reporting software can greatly improve your business by making it easier for you and your customers to understand the problem and feel confident that you fixed it.
The advanced analysis and decision-making support offered in FLIR Thermal Studio Pro includes a rich set of measurement tools, batch processing, the ability to pre-plan inspection routes, and customized report templates.
Become a Thermal Studio Expert
Learn to edit images, analyze them, and produce custom reports using FLIR Thermal Studio Suite software with online training from the Infrared Training Center. This virtual class covers everything you need to know, including:
- How to adjust image parameters and optimize thermal contrast
- How to create batch functions for image processing
- How to design a new report template
Never Worry About Your Camera Performance Again
Keep your camera going strong with FLIR CARE and FLIR PROTECT. FLIR CARE provides world-class calibration with performance verification and traceable calibration adjustment services that ensure your thermal data is always accurate. FLIR PROTECT extended warranty and service packages provide a full three years of coverage beyond the respective camera’s factory warranty. FLIR PROTECT customers can also receive a bundled calibration service, discounts on additional services, and options for fast-delivered loaner cameras.
Downloads
Specifications
- IR Resolution
- 128 × 96 pixels
- Thermal Sensitivity/NETD
- <70 mK
- Accuracy
- 0 to 100°C (32 to 212°F): ±3°C (±5.5°F); 100 to 300°C (212 to 572°F): ±3% [ambient temp. 15 to 35°C (59 to 95°F) and object temp. above 0°C (32°F)]
- Field of view (FOV)
- 53.6°
- Digital Camera
- 5 MP resolution
- Image Modes
- Infrared image, Visual image, MSX (Embossed visual details on thermal image), Picture-in-picture (IR area on visual image)
- Storage Media
- Internal memory and onboard FLIR Ignite cloud connectivity (with Wi-Fi)
Imaging & Optical
- Auto orientation
- Yes
- Camera software update
- Automatic over Wi-Fi, USB via computer
- Color
- Black
- Color Palettes
- Iron, Gray, Rainbow, Rainbow HC
- Detector Pitch
- 12 µm
- Detector Type
- Focal plane array, uncooled microbolometer
- Digital Camera
- 5 MP resolution
- Digital Camera FOV
- 71.5° × 56° (84° diagonal)
- Digital Zoom
- No
- Display resolution
- 640 × 480 pixels
- Field of view (FOV)
- 53.6°
- f-number
- 1.1
- Focus
- Focus free
- Gallery
- Thumbnails and custom folder structure
- Image Frequency
- 8.7 Hz
- Image Modes
- Infrared image, Visual image, MSX (Embossed visual details on thermal image), Picture-in-picture (IR area on visual image)
- IR Resolution
- 128 × 96 pixels
- Minimum Focus Distance
- Thermal: 0.1 m (0.32 ft), MSX: 0.3 m (0.98 ft)
- Spatial resolution (IFOV)
- 7.9 mrad/pixel
- Spectral Range
- 8 to 14 µm
- Thermal Sensitivity/NETD
- <70 mK
- Video Lamp
- Yes
Measurement & Analysis
- Accuracy
- 0 to 100°C (32 to 212°F): ±3°C (±5.5°F); 100 to 300°C (212 to 572°F): ±3% [ambient temp. 15 to 35°C (59 to 95°F) and object temp. above 0°C (32°F)]
- Camera size (L x W x H)
- 138 × 84 × 24 mm (5.4 × 3.3 × 0.94 in)
- Measurements correction
- Emissivity; matt/semi-matt/semi-gloss + custom value, Reflected apparent temperature, Atmospheric compensation
- Object Temperature Range
- -20 to 300°C (-4 to 572°F)
- Set-up Commands
- Local adaptation of units, language, date and time formats, Screen brightness (high, medium, low)
User Interface
- Display Technology
- IPS
- Languages
- Arabic, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, simplified Chinese, Spanish, Swedish, traditional Chinese, Turkish
- Text
- Soft keyboard on touchscreen
- Touchscreen
- Capacitive touch
Power
- Battery capacity
- 1800 mAh
- Battery charge life
- >500 cycles
- Battery operating time
- 4 hours
- Battery Type
- Rechargeable built-in Lithium ion battery
- Battery voltage
- 3.7 V
- Battery weight
- 40 g (1.4 oz)
- Charging system
- USB-C (1 A)
- Charging Temperature
- 35°C (95°F)
- Charging Time
- 2 hours
- External Power Operation
- 5 V, USB-C
- Power Management
- Adjustable stand-by and automatic shut-down
Environmental & Certifications
- Drop test
- 2 m (6.56 ft)
- EMC
- EN 301 487-1; EN 301 489-17; FCC 47 CFR Part 15 Class B
- Encapsulation
- Camera housing and lens: IP54 rated (IEC 60529)
- Humidity (Operating and Storage)
- IEC 60068-2-30/24 h 95% relative humidity 25 to 40°C (77 to 104°F) / 2 cycles
- Magnetic fields
- EN 61000-4-8 level 5
- Operating Temperature Range
- -10 to 50°C (14 to 122°F)
- Radio Spectrum
- ETSI EN 300 328; EN 301 489; FCC Title 47 CFR Part 15; RSS-247 Issue 2
- Relative Humidity
- 95% relative humidity 25 to 40°C (77 to 104°F) non-condensing
- Safety
- EN 62368-1
- Shock
- 25 g (IEC 60068-2-27)
- Storage Temperature Range
- -40 to 70°C (-40 to 158°F)
- Tripod Mounting
- UNC ¼”-20 (built-in)
- Vibration
- 2 g (IEC 60068-2-6)
- Warranty
- http://www.flir.com/warranty/
General
- Housing material
- PC and ABS, partially covered with TPE; aluminum
- Packaging Size
- 160 × 118 × 93 mm (6.3 × 4.6 × 3.7 in)
- Packaging Weight
- 0.52 kg (1.14 lb)
- Size (L x W x H)
- 138 × 84 × 24 mm (5.4 × 3.3 × 0.94 in)
